Serving Material



Serving Spools

62XS Serving
20% stronger and more durable than standard black and white serving due to a higher percentage of Spectra or Dyneema®. Grips well. Standard color is black. See available colors.

Approximate
Breaking Strength
Diameter
(inches)
Approximate Feet /
1 lb. spool
Spool Size
57 lbs. .018" 7,220 1/4 lb., 1 lb., or
100 yard jig
67 lbs. .021" 5,810 1/4 lb., 1 lb., or
75 yard jig
86 lbs. .025" 3,570 1/4 lb., 1 lb., or
60 yard jig




62 Braided Center Serving
Original blend of Spectra / Dyneema® and polyester. Grips well. Black/white color.

.018" spool sizes: 1 lb., or 100 yard jig
.021" spool sizes: 1 lb., or 75 yard jig
.025" spool sizes: 1 lb., or 60 yard jig




Polygrip Center Serving

Polygrip Center Serving
100% Polyester; grips very well. Black / white color. Very economical.

Polygrip Center Serving .020:
Approximate breaking strength: 35 lbs.
Diameter: .020"
Approximate feet per pound: 4,600
Spool sizes: 1 lb., or 75 yard jig

Polygrip Center Serving .025:
Approximate breaking strength: 50 lbs.
Diameter: .025"
Approximate feet per pound: 3,600
Spool sizes: 1 lb., or 60 yard jig




3D End Serving

3D End Serving
Small diameter available from three-ply twisted Dyneema® or Spectra material. Highly recommended for end servings. Servings should be tight but flexible. See available colors.

Approximate breaking strength: 60 lbs
Diameter: .016"
Approximate feet per pound: 9,500
Spool sizes: 1/4 lb., 1 lb., or 120 yard jig




Powergrip Serving

Powergrip Serving
A new blend of tightly braided spectra and nylon yarn. Tough and durable, Resin coated, grips well.

When serving with the smaller diameter servings, like 009, use less tension to avoid the serving material snagging on the spool.


Approximate
Breaking Strength
Diameter
(inches)
Approximate
Feet / Pound
Yards / Spool Used For:
25 lbs. .009" 17,500 150 yard jig spool End Serving
30 lbs. .014" 10,250 120 yard jig spool End or Center Serving
35 lbs. .018" 7,300 100 yard jig spool End or Center Serving
45 lbs. .021" 5,250 75 yard jig spool Center Serving
47 lbs. .025" 3,750 50 yard jig spool Center Serving
50 lbs. .032" 2,790 40 yard jig spool Crossbow Center Serving


Also offered in 1/4 lb. and 1 lb. spools. Stocked in Black and White, but see available colors.



Halo Serving Material

Halo Serving
100% tightly braided Spectra (or similar UHMPE) suitable for end or center serving. Highest durability. 014" white turns clearer when served tightly. See available colors.

When serving with the smaller diameter servings like Halo 007, use less tension to avoid the serving material snagging on the spool.


Approximate
Breaking Strength
Diameter
(inches)
Approximate Feet /
1 lb. spool
Spool Size
35 lbs. .007" 30,000 1/4 lb., 1 lb., or
150 yard jig
45 lbs. .014" 11,500 1/4 lb., 1 lb., or
120 yard jig
75 lbs. .017" 7,000 1/4 lb., 1 lb., or
100 yard jig
100 lbs. .019" 5,750 1/4 lb., 1 lb., or
75 yard jig
115 lbs. .021" 4,900 1 lb., or
75 yard jig
160 lbs. .024" 3,750 1 lb., or
45 yard jig
215 lbs. .030" 2,850 1 lb., or
40 yard jig




008 Serving Thread

008 Spectra Serving Thread
Small diameter fits well in all main string and cam grooves. Tough and durable, grips well, available in black, white, fluorescent green, fluorescent orange, blue, red, tan, and pink. More economical due to twisted construction

When serving with the smaller diameter servings like 008 Spectra, use less tension to avoid the serving material snagging on the spool.

Approximate breaking strength: 46 lbs
Diameter: .008"
Approximate feet per pound: 18,000
Spool sizes: 1/4 lb., 1 lb., 150 yard jig




2X End Serving

2X End Serving
100% Dyneema® or Spectra - small diameter. Fits snugly into wheel tracks and covers areas on strings and cables needing protection from abrasion. See available colors.

Approximate breaking strength: 50 lbs
Diameter: .011"
Approximate feet per pound: 14,200
Spool sizes: 1/4 lb., 1 lb., or 150 yard jig




400 Nylon Multifilament End Serving
The traditional end serving; also used for nock points and peeps. See available colors.

Approximate breaking strength: 30 lbs.
Diameter: .020"
Approximate feet per pound: 6,200
Spool sizes: 1 lb., or 90 yard jig




350 Nylon Braid Serving
Small diameter traditional end serving. Also used on FITA bows.

Approximate breaking strength: 15 lbs.
Diameter: .015"
Approximate feet per pound: 9,500
Spool sizes: 1 lb., or 125 yard jig




1200X Serving Material

1200X Serving Material
A very small thin strand of flat Spectra. A solution for buss cable serving separation problems. Also used on center serving to reduce wear from release. Served on its own or on top of existing serving. Available in black or white.

Spool Size: 120 yard jig spool




Nock Spools

Nock Point and Peep Tying Thread
100% high tenacity nylon, bonded to improve abrasion resistance. Will not fray when cut. High strength, weather resistant. Available in red or black.

Diameter: .020"
Approximate feet per pound: 5,000
Spool sizes: 75 yard jig, or 1 pound (5500 feet)




Bowstring and Serving Material Recommendations
Bowstring Recommended
Center Serving*
Recommended
End Serving
Normal Strand Count
(Compound)
452X Powergrip,
62XS or Halo
3D, 2X, Halo, or Powergrip .014 22/24
X-99 Powergrip,
62XS or Halo
3D, 2X, Halo, or Powergrip .014 28/30
Mercury Powergrip,
62XS or Halo
3D, 2X, Halo, or Powergrip .014 32
8125® Powergrip,
62XS or Halo
3D, 2X, Halo, or Powergrip .014 18/20
DynaFLIGHT 97 Powergrip,
62Xs, or Halo
3D, 2X, Halo, or Powergrip .014 14/16
(26/28 for crossbows)
450 Plus Powergrip,
62XS or Halo
3D, 2X, Halo, or Powergrip .014 12
652 Spectra/FF
(primarily recurve bows)
62 2S or 3D 18/20
B55 Polygrip 400 Nylon or .014" Powergrip 12/16


*Center serving size depends on the number of strands of bowstring

1) Halo Serving: recommended on any string material as a center serving where increased durability is required. It is often the preferred choice of finger shooters. It is extremely tough, but a little more difficult to hold in place. It can also be used as an end serving on recurves, again where high durability is required.

2) The recommendations are basic guidelines. The main factors being considered are: Nock fit, Arrow speed, String durability, and Safety

3) Use any good synthetic wax on BCY's bowstring materials (silicone blend recommended).




BCY manufactures and supplies products in accordance with these specifications. If used correctly, the material will serve the purpose for which it was intended - a bowstring or as a serving material. All products we manufacture are extensively tested. We offer a full range of material for the archery market. There are many variables which can significantly effect performance of the bowstring material. Some examples include: Number of strands and/or of twists, type of serving material, tightness of serving material, width of cam grooves on bow, amount of lubrication, type of release, condition of cam wheel, yoke system on cables, degree of string maintenance. As BCY cannot control these variables, BCY cannot accept responsibility for problems arising from strings, cables or servings.

8125 is a registered trademark of BCY
Dyneema is a registered trademark of DSM

Comparison to Brownell Serving Material: BCY products are made in the U.S.A., and we have prepared a document that compares BCY Serving Material with that made by Brownell. You can download that document here. Note that these comparisons were made with material being produced by Brownell in the USA. Now that Brownell is producing outside of the USA, we cannot be sure if these comparisons are still accurate.
